Applications
Solar tracking & cleaning systems, HVAC systems, Electric vehicles, Hand-held power tools
Description
BO42(100W) is a Outrunner Brushless DC Motor with 5800 RPM Speed and 17cNm Torque. It can combined with various types of gearboxes and drivers as per requirement. It has a 43mm diameter and 30mm height. These Motors are available with sensors and without sensors.
Robust Ball bearings ensure excellent service life with ≥ 5000 hours. Drivers are also available as an Add-On unit on special request. These motors are available at different speeds and different voltages on special request. These motors can combined with Planetary Gearboxes and Spur Gearboxes as per requirement.
Standard Data
| Motor type | Outrunner brushless DC motor |
| Configuration | 12N-16P |
| Ambient Temperature Operation | -40˚C to +100˚C |
| Storage & Transport Temperature | -60˚C to +120˚C |
| Weight | 140 g |
| Electrical Enclosure | IP 40 (As per IEC 60529) |
| Life expectancy | ≥5000 hours @ Rated Torque |
Technical Data
| Mechtex | Physical data | No load data | Data at Rated Torque | Stall | ||||||
| MODEL No. | Dia x height | Voltage | Speed | Current | Speed | Current | Torque | Power | Torque | Current |
| BO4230-24 | 43 x 30 mm | 24 VDC | 5800 RPM | 350 mA | 4250 RPM | 4.2 A | 17 cNm | 72 W(Out) | 234 cNm | 61 A |
| BO4230-18 | 43 x 30 mm | 18 VDC | 5250 RPM | 470 mA | 3470 RPM | 5.6 A | 18 cNm | 63 W(Out) | 175 cNm | 53 A |
*Other speed & voltages on special request
Available Customizations
| Sensorless |
| Inbuilt driver |
| Customized motor speed |
| Dust cover (Upto IP 65**) |
| 22 AWG x 200mm ends tinned and stripped |
| Customized shaft |
| Hollow shaft for robotics and gimbal applications |
Dimensional Drawing
