82mm Planetary Gearhead
GB82P

GB82P


82mm Planetary Gearhead

Applications

Robotic Lawn Mover Machine, Telecom Antenna, Solar Cleaning Robots, Medical Equipment, Automotive, Robotics

Description

GB82P is an 82mm planetary gearhead. It offers a gear torque range of 20Nm to 120Nm and a maximum gear ratio of 938.85. This gearbox features metal gears with plastic gears in the first stage and uses ball bearings to support higher torque and extend operational life.

This 82mm planetary gearhead is permanently lubricated for maintenance-free performance. It is ideal for applications such as automotive and robotics applications. It also combines with BLDC motors to meet various mechanical and automation needs.

Standard Data
Gear type   Spur Gears
Gear Torque Nm 20 to 120
Axial Load N 150
Radial force N 520
Output Bearings   Ball bearing
Output shafts mm Ø 19 (others on special request)
Ambient temperature operation °C -15….+80°C (+120°C on special request #)
Enclosure IP 40 (As per IEC 60529)

# Corresponding o/p torque rating of gearhead will be reduced.


Technical Data

Gearhead Data;

Reduction   3.71 5.18 13.73 19.2 26.85 35* 50.89 71.16 99.51 139.14 188.61 263.73 369.76 515.63 720.99 938.85*
Number of stages   1 1 2 2 2 2 3 3 3 3 4 4 4 4 4 4
Torque Nm 20 20 60 60 60 60 80 80 80 80 120 120 120 120 120 120
Gear Box Length (L) mm 60.4 60.4 81.4 81.4 81.4 81.4 102.4 102.4 102.4 102.4 123.4 123.4 123.4 123.4 123.4 123.4

Note: Ratios marked with * suffix available on special request


Dimensional Drawing
