Applications
- Suitable for a wide range of stepping motors, from NEMA frame size 17 to 34.
- It can be used in various kinds of machines, such as laser cutters, laser markers, high-precision X-Y tables, labeling machines, and so on.
- Its unique features make the Frank Pro an ideal solution for applications that require both low-speed smoothness and high-speed performance
Description
Frank Pro is 48V In-built Stepper Motor Driver for Nema 17, Nema 23, Nema 24, and Nema 34 with output current upto 3.2 Amps. It is a fully digital stepping driver with an advanced control algorithm.
The driven motors can run with much smaller noise, lower heating, and smoother movement. Its unique features make the Frank Pro an ideal solution for applications that require low-speed smoothness. The Frank Pro Driver embeds a comprehensive set of protection and diagnostic features for Stepper motors. This driver can combined with hybrid stepper motors as per requirements.
Standard Data
| Supply voltage up to 48 VDC |
| Output current up to 3.2A (RMS). |
| Pulse input frequency up to 500kHz |
| Micro step resolutions are programmable, from full-step to 1/256 step. |
| Optically isolated control signals. Under voltage, over current, phase error, thermal shutdown protection |
Technical Data
Electrical Connections
| Pin # | Function | Description |
| 1 | VM | Input Voltage (8V to 48V) |
| 2 | GND | Supply Ground |
Phase Output
| Pin # | Function | Description |
| 3 | A | Motor phase A |
| 4 | A' | |
| 5 | B | Motor Phase B |
| 6 | B' | |
| 7 | FLT- | Fault Output Signal |
| 8 | FLT+ | |
| 9 | EN- | Enable input Signal |
| 10 | En+ | |
| 11 | DIR- | Direction Input Signal |
| 12 | DIR+ | |
| 13 | STEP- | Step Input Signal (Step frequency upto 500KHz) |
| 14 | STEP+ |
Specifications
| Parameters | Unit | |||
| Min | Max | |||
| Supply Voltage | 8 | 48 | VDC | |
| Output Current | RMS Output Current | 3.2 | A | |
| Peak Output Current | 4.5 | A | ||
| Step Input Frequency | - | 500 | kHz | |
| Control Signal Voltage | 5 | 24 | V | |
| Control Signal Current | 0 | 10 | mA | |
| Ambient Temperature | -40 | 75 | °C | |
Connection Diagram
